RH1 Image Processor

We are providing FPGA based image processor RH1 with configurations of one, two or four sensors.

Features

  • Implemented on Xilinx Spartan or Altera Cyclone FPGA
  • 6-axis video stabilization
  • One to four camera streaming in, through MIPI-CSI2 or DVP interface
  • Real-time on-device processing
  • Distortion correction, rectification and perspective transformation
  • Multi-cam automatic stitching
  • Extendable angle tolerance with low-cost gimbal while keeping same compensation accuracy

Feel free to contact bd@quixotec.com for more detailed information.

Cost Comparison

Single 4k@30fps input, 1080p@30fps output
  • Conventional solution, at price 1.0 (normalized, baseline)
  • RH1:
    • <10k LUT
    • 333MHz 16-bit DRAM
    • 100MHz freq
    • Normalized price 0.6
Dual 4k@30fps input, 1080p@30fps output
  • Conventional solution, at normalized price 1.6
  • RH1:
    • <10k LUT
    • 333MHz 32-bit DRAM
    • 100MHz freq
    • Normalized price 0.8
Quad 4k@30fps input, Dual 4k output (VR ready)
  • Conventional solution, at normalized price 4.0
  • RH1:
    • <50k LUT
    • 333MHz 64-bit DRAM
    • 100MHz freq
    • Normalized price 1.6
